M24C04-WMN6 - STMicroelectronics
EEPROM Memory; 4kb; 512x8bit; 400kHz; serial I2C; 900ns; 2.5V-5.5V; -40+85 deg.C; SMD; SO8
Technical Details
| Access Time | 900ns |
| Case/Package | SOP |
| China RoHS | Non-Compliant |
| Density | 4kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Height | 1.5mm |
| Height - Seated (Max) | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.51 |
| Interface | Serial |
| Introduction Date | 1980-01-04 |
| Length | 4.9mm |
| Lifecycle Status | Obsolete |
| Max Frequency | 400kHz |
| Max Operating Temperature | 85°C |
| Max Supply Current | 2mA |
| Max Supply Voltage | 5.5V |
| Memory Type | EEPROM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 5V |
| Packaging | Bulk |
| REACH SVHC | Yes |
| RoHS | Non-Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 1.27mm |
| Voltage | 5V |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | NRND | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Atmel | Unknown | ||
| Microchip | Unknown | ||
| Microchip | Production |
