STCS1PUR - STMicroelectronics
1.5A MAX CONSTANT CURRENT LED DRIVER, QFN-8L P 0.5 mm, Tape and Reel
Technical Details
| Case/Package | DFN |
| China RoHS | Compliant |
| Height - Seated (Max) | 1mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Max Input Voltage | 40V |
| Max Operating Temperature | 125°C |
| Max Output Current | 1.5A |
| Max Supply Current | 750µA |
| Max Supply Voltage | 40V |
| Min Input Voltage | 4.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 750µA |
| Number of Channels | 1 |
| Number of Characters | 1 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 10 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 12V |
| Output Current | 1.5A |
| Output Current per Channel | 1.5A |
| Packaging | Tape and Reel |
| Quiescent Current | 450µA |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Temperature Grade | Automotive |
| Terminal Pitch | 500µm |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Future Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| MaxLinear | Obsolete | ||
| Intersil | Obsolete | ||
| Sipex | Unknown | ||
| Renesas | Obsolete | ||
| STMicroelectronics | Production | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | EOL | ||
| NXP Semiconductors | Obsolete |
