Technical Details
| Bandwidth | 100MHz |
| Case/Package | SMD/SMT |
| Frequency | 2.45GHz |
| Gain | 1.7dB |
| Height | 1.3mm |
| Impedance | 50Ω |
| Lead Free | Lead Free |
| Length | 10mm |
| Lifecycle Status | Production |
| Max Frequency | 2.5GHz |
| Max Length | 10.3mm |
| Max Operating Temperature | 80°C |
| Max Thickness | 1.3mm |
| Max Width | 4.3mm |
| Min Length | 9.7mm |
| Min Operating Temperature | -20°C |
| Min Thickness | 700µm |
| Min Width | 3.7mm |
| Mount | Surface Mount |
| Number of Bands | 1 |
| Number of Pins | 8 |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
