C1005C0G1H102J050BA - TDK
C Series 0402 1 nF 50 V ±5 % Tolerance C0G SMT Multilayer Ceramic Capacitor
Technical Details
| Capacitance | 1nF |
| Case/Package | 0402 |
| Case Code (Imperial) | 0402 |
| Case Code (Metric) | 1005 |
| China RoHS | Compliant |
| Depth | 500µm |
| Dielectric | C0G |
| Dielectric Material | Ceramic |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 500µm |
| Harmonized Tariff Schedule (HTS) Code | 8532.24.00.20 |
| Introduction Date | 2012-08-21 |
| Lead Free | Lead Free |
| Length | 1mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Material | Ceramic |
| Max Length | 1.05mm |
| Max Operating Temperature | 125°C |
| Max Width | 550µm |
| Min Length | 950µm |
| Min Operating Temperature | -55°C |
| Min Width | 450µm |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8532240020, 8532240020|8532240020|8532240020|8532240020|8532240020 |
| Temperature Coefficient | 30ppm/°C |
| Termination | SMD/SMT |
| Tolerance | 5% |
| Voltage | 50V |
| Voltage Rating | 50V |
| Voltage Rating (DC) | 50V |
| Weight | 652.039032µg |
| Width | 500µm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
