C3216X7R2E473K160AA - TDK
250V 47nF X7R 卤10% 1206 Multilayer Ceramic Capacitors MLCC - SMD/SMT ROHS
Technical Details
| Capacitance | 47nF |
| Case/Package | 1206 |
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| China RoHS | Compliant |
| Composition | Ceramic |
| Depth | 1.6mm |
| Dielectric | X7R |
| Dielectric Material | Ceramic |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8532.24.00.20 |
| Introduction Date | 2012-11-19 |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Material | Ceramic |
| Max Length | 3.4mm |
| Max Operating Temperature | 125°C |
| Max Width | 1.8mm |
| Min Length | 3mm |
| Min Operating Temperature | -55°C |
| Min Width | 1.4mm |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8532240020, 8532240020|8532240020|8532240020|8532240020|8532240020 |
| Termination | SMD/SMT |
| Thickness | 1.7526mm |
| Tolerance | 10% |
| Voltage | 250V |
| Voltage Rating | 250V |
| Voltage Rating (DC) | 250V |
| Weight | 16.187578mg |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
RS
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Murata | Production | ||
| TDK | Production | ||
| Walsin Technologies | Production | ||
| Samsung Electro-Mechanics | Production | ||
| TDK | Obsolete | ||
| KYOCERA AVX | Obsolete | ||
| TDK | Production | ||
| Murata | Production | ||
| TDK | Production | ||
| TDK | NRND |
