Technical Details
| Approvals | EN, IEC, UL |
| Connector Type | Power |
| Cord Length | 1.050036m |
| Current - Output 1 | 4.58A |
| Efficiency | 87% |
| Height | 43.942mm |
| Length | 169.926mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | CURRENT/AVAILABLE |
| Max Input Voltage | 264V |
| Max Input Voltage (AC) | 264V |
| Max Operating Temperature | 60°C |
| Max Output Current | 4.58A |
| Max Output Power | 165W |
| Max Output Voltage | 36.36V |
| Max Power Dissipation | 165W |
| Min Input Voltage | 90V |
| Min Input Voltage (AC) | 90V |
| Min Operating Temperature | 0°C |
| Min Output Voltage | 35.64V |
| Mount | Desktop |
| Nominal Input Voltage | 230V |
| Nominal Output Voltage | 36V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Output Power | 165W |
| Output Voltage | 36V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Commercial |
| Voltage - Output 1 | 36V |
| Weight | 816.466266g |
| Width | 85.09mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
