DTM300PW120D1 - TDK-Lambda
Ac-dc Power Supply, Medical & Ite Adapter, 12V, 25A, Class I, DTM300-D Series
Technical Details
| Approvals | CSA, EN, IEC, UL |
| Efficiency | 88% |
| Height - Seated (Max) | 45mm |
| Length | 222mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | CURRENT/AVAILABLE |
| Max Input Voltage | 264V |
| Max Operating Temperature | 60°C |
| Max Output Current | 25A |
| Max Output Power | 300W |
| Max Output Voltage | 12.6V |
| Min Input Voltage | 90V |
| Min Operating Temperature | -30°C |
| Min Output Voltage | 11.4V |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 12V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Output Power | 300W |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Width | 112mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
