DTM300PW240D2 - TDK-Lambda
Ac-dc Power Supply, Medical & Ite Adapter, 24V, 12.5A, Class II, DTM300-D Series
Technical Details
| Approvals | CSA, EN, IEC, UL |
| Efficiency | 88% |
| Height - Seated (Max) | 45mm |
| Introduction Date | 2019-02-05 |
| Length | 222mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | CURRENT/AVAILABLE |
| Max Input Voltage | 264V |
| Max Operating Temperature | 60°C |
| Max Output Current | 25A |
| Max Output Power | 300W |
| Max Output Voltage | 25.2V |
| Min Input Voltage | 90V |
| Min Operating Temperature | -30°C |
| Min Output Voltage | 22.8V |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 24V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Output Power | 300W |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8504409530 |
| Width | 112mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
