Technical Details
| Case/Package | 0201 |
| Core Material | Ferrite |
| Current Rating | 200mA |
| DC Resistance (DCR) | 700mΩ |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 300µm |
| Harmonized Tariff Schedule (HTS) Code | 8504.50.80.00 |
| Impedance | 33Ω |
| Introduction Date | 2016-07-25 |
| Length | 600µm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Length | 630µm |
| Max Operating Temperature | 125°C |
| Max Width | 330µm |
| Min Length | 570µm |
| Min Operating Temperature | -55°C |
| Min Width | 270µm |
| Number of Circuits | 1 |
| Number of Terminals | 2 |
| REACH SVHC | Yes |
| RMS Current (Irms) | 200mA |
| RoHS | Compliant |
| Series Resistance | 700mΩ |
| Test Frequency | 100MHz |
| Tolerance | 25% |
| Width | 300µm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
