MPZ0402S330CT000 - TDK
Ferrite Beads Multi-Layer Power 33Ohm 25% 100MHz 0.55A 0.18Ohm DCR 01005 T/R
Technical Details
| Core Material | Ferrite |
| Current Rating | 550mA |
| DC Resistance (DCR) | 180mΩ |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 200µm |
| Harmonized Tariff Schedule (HTS) Code | 8504.50.80.00 |
| Impedance | 33Ω |
| Introduction Date | 2017-09-14 |
| Length | 400µm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Length | 420µm |
| Max Operating Temperature | 125°C |
| Max Width | 220µm |
| Min Length | 380µm |
| Min Operating Temperature | -55°C |
| Min Width | 180µm |
| Number of Circuits | 1 |
| Number of Terminals | 2 |
| REACH SVHC | Yes |
| RMS Current (Irms) | 550mA |
| RoHS | Compliant |
| Schedule B | 8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000 |
| Series Resistance | 180mΩ |
| Test Frequency | 100MHz |
| Tolerance | 25% |
| Width | 200µm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
