PRASC1-16F-BBR00 - TE Connectivity / Alcoswitch
Switch Rocker ON OFF SPST Quick Connect Curved Rocker 16A 250VAC 372.85VA >100000Cycles Tray
Technical Details
| Actuator Length | 3.2004mm |
| Actuator Material | Nylon |
| Ambient Temperature Range High | 85°C |
| Case/Package | 125 |
| China RoHS | Compliant |
| Color | Black |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 125V |
| Country of Origin | Mainland China |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 6kcycles |
| ELV | Compliant |
| Height | 16.5mm |
| Housing Material | Nylon |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.40 |
| Illumination Color | Red |
| Illumination Type | Illuminated, LED |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2004-07-21 |
| Length | 21mm |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 250V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -20°C |
| Mount | Panel |
| Number of Positions | 2 |
| Operating Force | 6.37N |
| Ratings | Dust Proof |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | On-Off |
| Termination | Quick Connect |
| Throw Configuration | SPST |
| Type | Switch |
| VDE Tested | Yes |
| Voltage Rating (AC) | 125V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
