Connectors > Card Edge Connectors

1-146489-8 - TE Connectivity / AMP

Conn Board Stacker HDR 36 POS 2.54mm Solder ST Thru-Hole

Approvals	CSA
China RoHS	Non-Compliant
Connector Type	Header, Pin, Plug
Contact Current Rating	3A
Contact Gender	Male
Contact Plating	Lead, Nickel, Tin
Contact Shape	Square
Current Rating	3A
Dielectric Material	Polyethylene
Export Control Classification Number (ECCN) Code	EAR99
ELV	Non-Compliant
Flammability Rating	UL94 V-0
Gender	Male
Housing Color	Black
Housing Material	Thermoplastic
Harmonized Tariff Schedule (HTS) Code	8536.69.40.40
Insulation Resistance	5GΩ
Introduction Date	1999-07-23
Lead Length	18.77mm
Lifecycle Status	Obsolete
Mating Post Length	2.7686mm
Max Operating Temperature	125°C
Min Operating Temperature	-65°C
Mount	Through Hole
Number of Contacts	36
Number of Pins	36
Number of Ports	1
Number of Positions	36
Number of Rows	2
Orientation	Vertical
PCB Mounting Orientation	Vertical
Pitch	2.54mm
Plating Thickness	5.08µm
Radiation Hardening	No
REACH SVHC	No
RoHS	Non-Compliant
Row Spacing	2.54mm
Shielding	Unshielded
Stackable	Yes
Stack Height	12.7mm
Tail Length	3.28mm
Terminal Pitch	2.54mm
Termination	Through Hole

RoHS : Unconfirmed

Radiation Hardening : No

REACH SVHC : No

Obsolete
