DTM04-3P - TE Connectivity / DEUTSCH
Automotive Rectangular DC Connector Housing, 3 Pin Female Receptacle, Dtm Series
Technical Details
| China RoHS | Compliant |
| Color | Grey |
| Connector Type | Socket |
| Contact Current Rating | 7.5A |
| Contact Gender | Male |
| Current Rating | 7.5A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Gender | Receptacle |
| Height | 16.2052mm |
| Housing Color | Grey |
| Housing Material | Thermoplastic |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Hybrid Connector | No |
| Introduction Date | 2012-09-04 |
| Length | 41.148mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Number of Contacts | 3 |
| Number of Pins | 3 |
| Number of Ports | 1 |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Operating Supply Voltage | 250V |
| Packaging | Box |
| Pitch | 4mm |
| Polarized | Yes |
| REACH SVHC | No |
| RoHS | Compliant |
| Serviceable | Yes |
| Shielding | Unshielded |
| Terminal Pitch | 4.19mm |
| Voltage Rating | 250V |
| Width | 20.73mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
