1-1418448-1 - TE Connectivity
Automotive Connector Housing, MCP 1.5K, Receptacle, 3 Ways, AMP MCP 1.5K Series Power Contacts
Technical Details
| Body Material | PBT |
| China RoHS | Compliant |
| Circuit Application | Signal |
| Color | Black |
| Connector Type | Socket |
| Contact Current Rating | 20A |
| Contact Gender | Female |
| Current Rating | 20A |
| Depth | 30.75mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Height | 30.75mm |
| Housing Color | Black |
| Housing Material | PBT |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Hybrid Connector | No |
| Introduction Date | 2014-01-20 |
| Length | 35.9918mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Mating Tab Width | 1.6002mm |
| Max Operating Temperature | 140°C |
| Min Operating Temperature | -40°C |
| Mount | Cable |
| Number of Contacts | 3 |
| Number of Pins | 3 |
| Number of Ports | 1 |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Pitch | 3.9878mm |
| Polarized | Yes |
| Ratings | IP67 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Serviceable | Yes |
| Shielding | Unshielded |
| Terminal Pitch | 4mm |
| Voltage Rating | 60V |
| Width | 18.4912mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
