1-967623-1 - TE Connectivity
Conn Housing RCP 15 POS 5mm Crimp ST Cable Mount Automotive Carton
Technical Details
| Body Material | PBT |
| China RoHS | Compliant |
| Circuit Application | Signal |
| Color | Violet |
| Connector Type | Receptacle, Socket |
| Contact Gender | Female |
| Depth | 26.5mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Gender | Receptacle |
| Height | 26.4922mm |
| Housing Color | Violet |
| Housing Material | Polybutylene |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Hybrid Connector | No |
| Insulation Material | PBT |
| Introduction Date | 2001-11-01 |
| Lead Free | Not Applicable |
| Length | 26.1874mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Mating Tab Width | 2.794mm |
| Max Operating Temperature | 110°C |
| Min Operating Temperature | -40°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 15 |
| Number of Pins | 15 |
| Number of Ports | 1 |
| Number of Positions | 15 |
| Number of Rows | 3 |
| Orientation | Straight |
| Packaging | Carton |
| Pitch | 5mm |
| Polarized | Yes |
| Radiation Hardening | No |
| Ratings | IP67 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 5.5118mm |
| Schedule B | 8538907080|8538907080|8538907080|8538907080|8538907080 |
| Serviceable | No |
| Shielding | Unshielded |
| Terminal Pitch | 5mm |
| Termination | Crimp |
| Width | 26.5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
