1571610-2 - TE Connectivity
Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24V 1000000Cycles 1.57N Thru-Hole Bulk
Technical Details
| Actuator Length | 3.85mm |
| Actuator Material | Nylon, Polyamide |
| China RoHS | Compliant |
| Color | Black |
| Contact Current Rating | 50mA |
| Contact Material | Stainless Steel |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 50mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Height | 8mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.40 |
| Illumination Type | Illuminated, Non-Illuminated |
| Introduction Date | 2014-01-20 |
| Length | 6.9mm |
| Life (Cycles) | 1Mcycles |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 50mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 24V |
| Mechanical Life | 1Mcycles |
| Min Operating Temperature | -35°C |
| Mount | Through Hole |
| Number of Positions | 1 |
| Operating Force | 1.274N |
| Orientation | Right Angle |
| Packaging | Bulk |
| Ratings | Dust Tight, IP67, Waterproof |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | IP67 |
| Switch Function | Off-Mom |
| Switch Travel | 350µm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Type | Switch |
| Voltage Rating (DC) | 24V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
