3-1825910-2 - TE Connectivity
Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 100000Cycles 2.55N Thru-Hole Loose
Technical Details
| Actuator Length | 13.3858mm |
| Actuator Material | Nylon, Polyamide |
| China RoHS | Compliant |
| Color | Black, Red |
| Contact Current Rating | 50mA |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 50mA |
| Depth | 7.8mm |
| Electrical Life | 100kcycles |
| ELV | Compliant |
| Height | 3.61mm |
| Housing Material | Nylon |
| Length | 5.99mm |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 50mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 24V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -35°C |
| Mount | Through Hole |
| Number of Positions | 1 |
| Operating Force | 2.548N |
| Orientation | Straight |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | PC Pins, Solder |
| Throw Configuration | SPST |
| Type | Switch |
| Voltage Rating (DC) | 24V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
