3-435640-5 - TE Connectivity
Switch DIP OFF ON SPST 4 Raised Rocker 0.06A 24VDC PC Pins 2.54mm Thru-Hole Loose Piece
Technical Details
| Actuator Length | 1.27mm |
| Actuator Material | Thermoplastic |
| Approvals | UL |
| China RoHS | Non-Compliant |
| Color | Blue, White |
| Contact Current Rating | 1A |
| Contact Plating | Gold |
| Contact Resistance | 100mΩ |
| Country of Origin | Mexico |
| Current Rating | 400mA |
| Depth | 9.65mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 2kcycles |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Height | 7.37mm |
| Housing Color | Blue |
| Housing Material | Polyester |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.65 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 1999-01-01 |
| Lead Length | 3.556mm |
| Length | 12.19mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 1A |
| Max Operating Temperature | 105°C |
| Max Voltage Rating (DC) | 40V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Circuits | 4 |
| Number of Poles | 1 |
| Number of Positions | 4 |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Non-Compliant |
| Terminal Pitch | 2.54mm |
| Termination | PC Pins |
| Throw Configuration | SPST |
| Type | Switch |
| Voltage Rating (DC) | 5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
