ISO7241MDWR - Texas Instruments
Digital Isolator Cmos 4-CH 150MBPS 16-PIN SOIC T/r / Dgtl Iso 2.5KV Gen Purp 16SOIC
Technical Details
| Case/Package | SOIC |
| Channel Type | Unidirectional |
| Contact Plating | Gold |
| Data Rate | 150Mbps |
| Height | 2.65mm |
| Isolated Power | No |
| Lead Free | Lead Free |
| Length | 10.3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3.3V |
| Nominal Supply Current | 18mA |
| Number of Channels | 4 |
| Number of Pins | 16 |
| Packaging | Tape & Reel (TR) |
| Propagation Delay | 23ns |
| Pulse Width Distortion (PWD) | 2ns |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Thickness | 2.35mm |
| Turn-On Delay Time | 19ns |
| Type | General Purpose |
| Weight | 420.395078mg |
| Width | 7.5mm |
Compliance
RoHS : Unconfirmed
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Obsolete | ||
| Texas Instruments | Production | ||
| Silicon Lab | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production |
