LM3402HVMM/NOPB - Texas Instruments
0.5A Constant Current Buck Regulator For High Power Led Drivers, 8 Pin MSOP
Technical Details
| Case/Package | VSSOP |
| Contact Plating | Tin |
| Efficiency | 96% |
| Frequency | 1MHz |
| Height | 0m |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 75V |
| Max Operating Temperature | 125°C |
| Max Output Current | 500mA |
| Max Output Voltage | 40V |
| Max Supply Current | 900µA |
| Min Input Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 200mV |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 500mA |
| Output Type | Adjustable |
| Quiescent Current | 600µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1MHz |
| Thickness | 970µm |
| Topology | Buck |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| Diodes Inc. | Obsolete | ||
| Analog Devices | Obsolete | ||
| Analog Devices | Unknown | ||
| Microchip | Production | ||
| Renesas | Obsolete | ||
| Analog Devices | Unknown | ||
| Diodes Inc. | Obsolete | ||
| Analog Devices | Unknown |
