LM3402HVMR/NOPB - Texas Instruments
0.5A Constant Current Buck Regulator For High Power Led Drivers, 8 Pin Psop
Technical Details
| Case/Package | SOP |
| Contact Plating | Tin |
| Dropout Voltage | 300mV |
| Efficiency | 96% |
| Frequency | 1MHz |
| Height | 1.7mm |
| Lead Free | Lead Free |
| Length | 4.89mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 75V |
| Max Operating Temperature | 125°C |
| Max Output Current | 500mA |
| Max Supply Current | 900µA |
| Min Input Voltage | 6V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 500mA |
| Output Type | Adjustable |
| Quiescent Current | 600µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 1MHz |
| Thickness | 1.48mm |
| Topology | Buck |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
