LM3404HVMA/NOPB - Texas Instruments
75-V 1.0A constant current buck LED driver 8-SOIC -40 to 125
Technical Details
| Case/Package | SOIC |
| Contact Plating | Tin |
| Height | 1.75mm |
| High Level Output Current | 1A |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Low Level Output Current | 1.2A |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 75V |
| Max Operating Temperature | 125°C |
| Max Supply Current | 900µA |
| Max Supply Voltage | 75V |
| Min Input Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 6V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of LEDs | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Segments | 1 |
| Output Current | 1A |
| Output Voltage | 73V |
| Quiescent Current | 625µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 1MHz |
| Thickness | 1.58mm |
| Topology | Buck |
| Width | 3.91mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| MaxLinear | Obsolete | ||
| Diodes Inc. | Production | ||
| onsemi | EOL | ||
| Diodes Inc. | Obsolete | ||
| Infineon | Obsolete | ||
| Diodes Inc. | NRND | ||
| MaxLinear | Obsolete | ||
| MaxLinear | Obsolete | ||
| MaxLinear | Obsolete |
