LM3404MR/NOPB - Texas Instruments
42-V 1.0-A constant current buck LED driver 8-SO PowerPAD -40 to 125
Technical Details
| Case/Package | SOP |
| Contact Plating | Tin |
| Frequency | 1MHz |
| Height | 1.7mm |
| High Level Output Current | 1A |
| Lead Free | Lead Free |
| Length | 4.89mm |
| Lifecycle Status | Production |
| Low Level Output Current | 1.2A |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 42V |
| Max Operating Temperature | 125°C |
| Max Output Voltage | 40V |
| Max Supply Current | 900µA |
| Max Supply Voltage | 42V |
| Min Input Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 200mV |
| Min Supply Voltage | 6V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Segments | 1 |
| Output Current | 1A |
| Output Voltage | 7V |
| Quiescent Current | 625µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1MHz |
| Thickness | 1.48mm |
| Topology | Buck |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
