LM3405AXMK/NOPB - Texas Instruments
Texas Instruments LM3405AXMK/NOPB. IC Led Driver Const Current/buck TSOT236, Full Reel
Technical Details
| Case/Package | TSOT |
| Contact Plating | Tin |
| Frequency | 1.9MHz |
| Height | 1.1mm |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 22V |
| Max Operating Temperature | 125°C |
| Max Output Voltage | 20V |
| Max Supply Current | 2.8mA |
| Max Supply Voltage | 15V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 200mV |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 6 |
| Number of Segments | 1 |
| Output Current | 1A |
| Output Voltage | 20V |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 1.8mA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 1.6MHz |
| Thickness | 870µm |
| Topology | Buck |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
