LM3409MY/NOPB - Texas Instruments

42-V PFET buck controller for high power LED drives 10-HVSSOP -40 to 125

Technical Details

Case/Package	MSOP
Contact Plating	Tin
Efficiency	97%
Frequency	1MHz
Height	1.1mm
Lead Free	Lead Free
Length	3mm
Lifecycle Status	Production
Manufacturer Lifecycle Status	ACTIVE
Max Input Voltage	42V
Max Operating Temperature	125°C
Max Output Current	5A
Max Output Voltage	42V
Max Supply Current	2mA
Max Supply Voltage	42V
Min Input Voltage	6V
Min Operating Temperature	-40°C
Min Supply Voltage	6V
Mount	Surface Mount
Number of Outputs	1
Number of Pins	10
Output Current	5A
Output Voltage	42V
Quiescent Current	2mA
Radiation Hardening	No
REACH SVHC	No
RoHS	Compliant
Schedule B	8542390000, 8542390000\|8542390000\|8542390000\|8542390000\|8542390000
Switching Frequency	2MHz
Termination	SMD/SMT
Thickness	1.02mm
Topology	Buck
Width	3mm

Compliance

RoHS : Unconfirmed

Radiation Hardening : No

REACH SVHC : No
