LM3414MRX/NOPB - Texas Instruments
Tape & Reel (TR) LM3414 Step-Down (Buck) Analog PWM led driver 4.89mm 3.5mA 42V 250kHz
Technical Details
| Dimming | Analog, PWM |
| Frequency | 500kHz |
| Height | 1.7mm |
| Lead Free | Lead Free |
| Length | 4.89mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 42V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 3.5mA |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 1A |
| Output Current per Channel | 1A |
| Output Voltage | 42V |
| Quiescent Current | 3.2mA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 250kHz |
| Thickness | 1.48mm |
| Topology | Buck |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
