LM3450AMT/NOPB - Texas Instruments
LED drivers with active power factor correction and phase dimming decoder 16-TSSOP
Technical Details
| Case/Package | TSSOP |
| Height | 1.2mm |
| High Level Output Current | -1.5A |
| Lead Free | Lead Free |
| Length | 5mm |
| Lifecycle Status | Production |
| Low Level Output Current | 1.5A |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 20V |
| Max Operating Temperature | 125°C |
| Max Supply Current | 1.6mA |
| Max Supply Voltage | 20V |
| Min Input Voltage | 8.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 8.5V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Output Current | 1.5A |
| Output Voltage | 60V |
| Packaging | Rail/Tube |
| Quiescent Current | 1.6mA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 460Hz |
| Thickness | 1mm |
| Topology | Boost, Flyback |
| Weight | 4.535924g |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
