LM3537TME/NOPB - Texas Instruments
Tape & Reel (TR) LM3537 Switched Capacitor (Charge Pump) PWM led driver 0m 25mA 5.5V 1.3MHz
Technical Details
| Dimming | PWM |
| Frequency | 1.3MHz |
| Height | 675µm |
| Lead Free | Lead Free |
| Length | 0m |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 110°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -30°C |
| Mount | Surface Mount |
| Number of Channels | 8 |
| Number of Outputs | 8 |
| Number of Pins | 30 |
| Number of Segments | 8 |
| Output Current per Channel | 25mA |
| Output Voltage | 4V |
| Packaging | Tape & Reel |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 420µm |
| Topology | Boost |
| Touchscreen | Capacitive |
| Width | 0m |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
