LM3679UR-1.2/NOPB - Texas Instruments
3MHz, 350mA Miniature Step-Down DC-DC Converter for Ultra Low Profile Applications 5-DSBGA
Technical Details
| Efficiency | 93% |
| Height | 425µm |
| Lead Free | Lead Free |
| Length | 0m |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Output Current | 350mA |
| Max Output Power | 630mW |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -30°C |
| Min Output Voltage | 1.2V |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 5mA |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Operating Supply Voltage | 5.5V |
| Output Configuration | Positive |
| Output Current | 350mA |
| Output Type | Fixed |
| Output Voltage | 1.2V |
| Packaging | Tape & Reel |
| Quiescent Current | 16µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 3MHz |
| Synchronous Rectifier | Yes |
| Thickness | 220µm |
| Topology | Buck |
| Width | 0m |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
