LM5015MHE/NOPB - Texas Instruments
4.25-75V, Monolithic Two-Switch Forward DC-DC egulator 14-HTSSOP -40 to 125
Technical Details
| Case/Package | HTSSOP EP |
| Contact Plating | Tin |
| Efficiency | 87% |
| Height | 1.2mm |
| Lead Free | Lead Free |
| Length | 5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 75V |
| Max Operating Temperature | 125°C |
| Max Output Current | 1.2A |
| Max Output Voltage | 37V |
| Min Input Voltage | 4.75V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.26V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 14 |
| Operating Supply Voltage | 75V |
| Output Current | 1.2A |
| Output Type | Adjustable |
| Output Voltage | 37V |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 110µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 750kHz |
| Synchronous Rectifier | No |
| Thickness | 1mm |
| Topology | Boost, Buck, Flyback |
| Width | 4.4mm |
