LM5100BMAX/NOPB - Texas Instruments
2-A, 100-V half bridge gate driver with 8-V UVLO and CMOS inputs 8-SOIC -40 to 125
Technical Details
| Case/Package | SOIC |
| Fall Time | 430ns |
| Height | 1.75mm |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Output Current | 2A |
| Max Supply Voltage | 14V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 9V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Drivers | 2 |
| Number of Outputs | 2 |
| Number of Pins | 8 |
| Operating Supply Current | 2mA |
| Output Current | 2A |
| Packaging | Tape & Reel |
| Propagation Delay | 20ns |
| Quiescent Current | 200µA |
| Radiation Hardening | No |
| Rise Time | 570ns |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|85 |
| Thickness | 1.58mm |
| Turn-Off Delay Time | 1ns |
| Turn-On Delay Time | 1ns |
| Weight | 142.994995mg |
| Width | 3.91mm |
