LP2987AILD-5.0/NOPB - Texas Instruments
200-mA, 16-V, low-dropout voltage regulator with power good & enable 8-WSON -40 to 125
Technical Details
| Accuracy | 0.8% |
| Current Rating | 200mA |
| Dropout Voltage | 180mV |
| Height | 800µm |
| Lead Free | Lead Free |
| Length | 4mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 16V |
| Max Operating Temperature | 125°C |
| Max Output Current | 200mA |
| Min Current Limit | 250mA |
| Min Input Voltage | 2.1V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Regulators | 1 |
| Output Current | 200mA |
| Output Type | Fixed |
| Output Voltage | 5V |
| Output Voltage Accuracy | 0.8% |
| Packaging | Tape and Reel |
| Polarity | Positive |
| Quiescent Current | 100µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 800µm |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
