LP5520TL/NOPB - Texas Instruments
LED Driver 12 Segment 1400uA Supply Current 25-Pin DSBGA T/R
Technical Details
| Case/Package | SMD/SMT |
| Contact Plating | Copper, Silver, Tin |
| Features | I²C |
| Frequency | 19.52kHz |
| Height | 675µm |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Low Level Output Current | 60mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Supply Current | 1.4mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 2.9V |
| Min Operating Temperature | -30°C |
| Min Supply Voltage | 2.9V |
| Mount | Surface Mount |
| Nominal Supply Current | 1.4mA |
| Number of Channels | 3 |
| Number of Outputs | 3 |
| Number of Pins | 25 |
| Number of Segments | 12 |
| Output Current | 60mA |
| Output Voltage | 20V |
| Quiescent Current | 900µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 1.22MHz |
| Thickness | 675µm |
| Topology | Boost |
| Width | 2.8mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| STMicroelectronics | Obsolete | ||
| Texas Instruments | Production | ||
| Texas Instruments | Unknown | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Unknown |
