LP5521TMX/NOPB - Texas Instruments
Tape & Reel (TR) LP5521 Switched Capacitor (Charge Pump) I2C led driver 0m 25.5mA 5.5V 1.25MHz
Technical Details
| Contact Plating | Copper, Silver, Tin |
| Features | I²C |
| Frequency | 1.25MHz |
| Height | 675µm |
| High Level Output Current | 25.5mA |
| Lead Free | Lead Free |
| Length | 0m |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 85°C |
| Max Supply Current | 1.5mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -30°C |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Nominal Supply Current | 1.5mA |
| Number of Channels | 3 |
| Number of Outputs | 3 |
| Number of Pins | 20 |
| Number of Segments | 3 |
| Output Voltage | 4.55V |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 1.5mA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Switching Frequency | 1.25MHz |
| Thickness | 420µm |
| Topology | Boost, Charge Pump |
| Width | 0m |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
