MSP430F6724IPN - Texas Instruments
MCU 16-bit MSP430 RISC 96KB Flash 2.5V/3.3V 80-Pin LQFP Tray
Technical Details
| Case/Package | LQFP |
| Core Architecture | RISC |
| Data Bus Width | 16b |
| Frequency | 25MHz |
| Height | 1.6mm |
| Interface | I2C, IrDA, LIN, SCI, SPI, UART, USART |
| Lead Free | Lead Free |
| Length | 12mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Frequency | 25MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 96kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of A/D Converters | 8 |
| Number of ADC Channels | 8 |
| Number of GPIO | 72 |
| Number of I/Os | 52 |
| Number of Pins | 80 |
| Number of Programmable I/O | 52 |
| Number of Timers/Counters | 4 |
| Number of UART Channels | 3 |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT |
| Radiation Hardening | No |
| RAM Size | 4kB |
| RoHS | Compliant |
| Thickness | 1.4mm |
| Watchdog Timer | Yes |
| Width | 12mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production |
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| DigiKey |
DE: 0
|
$ | 5.6913 | 5.6913 | ||||||
| Arrow Electronics |
US: 0
|
$ | 5.049 | 4.948 | ||||||
| Texas Instruments |
US: 3677
|
$ | 6.826 | 6.826 | 6.826 | 5.565 | 3.71 | 3.71 | ||
