SN54LS595J - Texas Instruments
Shift Register Single 8-Bit Serial to Serial/Parallel 16-Pin CDIP Tube
Technical Details
| Case/Package | CDIP |
| Direction | Unidirectional |
| Height | 5.08mm |
| Lead Free | Contains Lead |
| Length | 19.56mm |
| Lifecycle Status | Production |
| Logic Function | Shift Register |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Elements | 1 |
| Number of Pins | 16 |
| Operating Supply Voltage | 5V |
| Output Type | TTL |
| Packaging | Rail/Tube |
| Propagation Delay | 38ns |
| Radiation Hardening | No |
| RoHS | Non-Compliant |
| Schedule B | 8542390000 |
| Thickness | 4.57mm |
| Turn-On Delay Time | 38ns |
| Width | 6.92mm |
