SN65HVD54DR - Texas Instruments
High Output Full-duplex RS-485 Driver and Receiver with enables 14-SOIC -40 to 85
Technical Details
| Case/Package | SOIC |
| Data Rate | 5Mbps |
| Height | 0m |
| Lead Free | Lead Free |
| Length | 8.65mm |
| Lifecycle Status | Production |
| Logic Function | Receiver |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Nominal Supply Current | 8mA |
| Number of Circuits | 256 |
| Number of Drivers | 1 |
| Number of Pins | 14 |
| Number of Receivers | 1 |
| Number of Transceivers | 1 |
| Number of Transmitters | 1 |
| Operating Supply Voltage | 5V |
| RoHS | Compliant |
| Simplex/Duplex | Full Duplex |
| Thickness | 1.58mm |
| Weight | 130.010913mg |
| Width | 3.91mm |
Compliance
RoHS : Unconfirmed
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | NRND | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Obsolete | ||
| Renesas | Obsolete | ||
| Texas Instruments | Unknown | ||
| MaxLinear | Obsolete | ||
| Texas Instruments | Obsolete | ||
| Texas Instruments | Obsolete | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production |
