SN74AHCT594PWR - Texas Instruments
IC 8-BIT SHIFT REGISTER 16-TSSOP Shift Shift Register 1 Element 8 Bit 16-TSSOP
Technical Details
| Case/Package | TSSOP |
| Direction | Unidirectional |
| Height | 1.2mm |
| Lead Free | Lead Free |
| Length | 5mm |
| Lifecycle Status | Production |
| Logic Function | Shift Register |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Input Lines | 1 |
| Number of Output Lines | 9 |
| Number of Pins | 16 |
| Operating Supply Voltage | 5V |
| Packaging | Tape & Reel (TR) |
| Propagation Delay | 9.2ns |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 1mm |
| Turn-On Delay Time | 10.7ns |
| Weight | 61.887009mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
