SN74HCS165BQBR - Texas Instruments
IC SHIFT REGISTER 8 BIT 16WQFN Shift Shift Register 1 Element 8 Bit 16-WQFN (2.5x3.5)
Technical Details
| Ambient Temperature Range High | 125°C |
| Frequency | 170MHz |
| Height | 800µm |
| Length | 3.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2V |
| Nominal Supply Current | 100nA |
| Number of Bits | 8 |
| Number of Circuits | 1 |
| Number of Inputs | 8 |
| Number of Outputs | 2 |
| Number of Pins | 16 |
| Propagation Delay | 17ns |
| RoHS | Compliant |
| Thickness | 750µm |
| Width | 2.5mm |
Compliance
RoHS : Unconfirmed
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Nexperia | Production | ||
| Nexperia | Production | ||
| Nexperia | EOL | ||
| Nexperia | Production | ||
| Nexperia | Production | ||
| Nexperia | Obsolete | ||
| Nexperia | Production | ||
| Nexperia | Production | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Obsolete |
