SN74LVC1G99DCTR - Texas Instruments
Ultra-Configurable Multi-Function Gate With 3-State Outputs 8-SSOP -40 to 125
Technical Details
| Case/Package | SSOP |
| Contact Plating | Gold |
| Height | 1.3mm |
| High Level Output Current | -32mA |
| Length | 2.95mm |
| Lifecycle Status | Production |
| Logic Function | Multi Function |
| Low Level Output Current | 32mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.65V |
| Mount | Surface Mount |
| Number of Bits | 1 |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Gates | 1 |
| Number of Input Lines | 2 |
| Number of Inputs | 4 |
| Number of Output Lines | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 32mA |
| Propagation Delay | 8.6ns |
| Quiescent Current | 10µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schmitt Trigger Input | Yes |
| Thickness | 1.29mm |
| Weight | 23.388357mg |
| Width | 2.8mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
