SNJ54ACT10W - Texas Instruments
Military 3-ch, 3-input, 4.5-V to 5.5-V NAND gates with TTL-compatible CMOS inputs 14-CFP -55 to 125
Technical Details
| Height | 2.03mm |
| High Level Output Current | -24mA |
| Lead Free | Contains Lead |
| Length | 9.21mm |
| Lifecycle Status | Production |
| Logic Function | NAND |
| Low Level Output Current | 24mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Bits | 3 |
| Number of Elements | 3 |
| Number of Gates | 3 |
| Number of Outputs | 1 |
| Number of Pins | 14 |
| Operating Supply Voltage | 5V |
| Output Type | CMOS |
| Packaging | Rail/Tube |
| Propagation Delay | 10ns |
| Quiescent Current | 4µA |
| Radiation Hardening | No |
| RoHS | Non-Compliant |
| Thickness | 1.59mm |
| Width | 5.97mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
