TLC59108IRGYR - Texas Instruments
8-bit Fast Mode Plus (FM+) I2C Bus constant-current LED sink driver 20-VQFN -40 to 85
Technical Details
| Case/Package | VQFN |
| Frequency | 25MHz |
| Height | 1mm |
| Lead Free | Lead Free |
| Length | 4.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Output Current | 120mA |
| Max Supply Current | 17mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 28mA |
| Number of Outputs | 8 |
| Number of Pins | 20 |
| Output Current | 120mA |
| Output Current per Channel | 120mA |
| Output Voltage | 17V |
| Packaging | Cut Tape (CT) |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 900µm |
| Topology | Boost |
| Width | 3.5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
