TLC5916IPW - Texas Instruments
8-bit constant-current LED sink driver 16-TSSOP -40 to 125
Technical Details
| Case/Package | TSSOP |
| Contact Plating | Gold |
| Frequency | 30MHz |
| Height | 1.2mm |
| High Level Output Current | -1mA |
| Lead Free | Lead Free |
| Length | 5mm |
| Lifecycle Status | Production |
| Low Level Output Current | 1mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 125°C |
| Max Output Current | 120mA |
| Max Power Dissipation | 900mW |
| Max Supply Current | 22mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 22mA |
| Number of Channels | 8 |
| Number of Outputs | 8 |
| Number of Pins | 16 |
| Number of Segments | 8 |
| Output Current | 120mA |
| Output Voltage | 17V |
| Power Dissipation | 900mW |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 30MHz |
| Thickness | 1mm |
| Topology | Boost |
| Weight | 61.887009mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
