TLC5920DLRG4 - Texas Instruments
16-channel LED driver with 10Mhz data transfer rate 48-SSOP -20 to 85
Technical Details
| Case/Package | SSOP |
| Frequency | 10MHz |
| Height | 2.79mm |
| High Level Output Current | -30mA |
| Lead Free | Lead Free |
| Length | 15.88mm |
| Lifecycle Status | Production |
| Low Level Output Current | 640mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 1.5W |
| Max Supply Current | 1.6mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 4.5V |
| Min Operating Temperature | -20°C |
| Min Supply Voltage | 4.5V |
| Nominal Supply Current | 1.6mA |
| Number of Outputs | 16 |
| Number of Pins | 48 |
| Number of Segments | 128 |
| Operating Supply Voltage | 5V |
| Packaging | Tape & Reel (TR) |
| Power Dissipation | 1.5W |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 2.59mm |
| Weight | 600.301152mg |
| Width | 7.49mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
