TLC59210IPWR - Texas Instruments
IC LED DRIVER PS 200MA 20TSSOP LED Driver IC 8 Output Power Switch Dimming 200mA 20-TSSOP
Technical Details
| Case/Package | TSSOP |
| Frequency | 1MHz |
| Height | 0m |
| Lead Free | Lead Free |
| Length | 6.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Supply Current | 5µA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 5µA |
| Number of Outputs | 8 |
| Number of Pins | 20 |
| Number of Segments | 8 |
| Output Current | 200mA |
| Output Voltage | 30V |
| Packaging | Cut Tape (CT) |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 1mm |
| Weight | 76.997305mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| ROHM | Production | ||
| Diodes Inc. | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| NXP Semiconductors | Production | ||
| Diodes Inc. | Production | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Production | ||
| MaxLinear | Obsolete |
