TLC5924DAPG4 - Texas Instruments
16-Channel LED Driver w/DOT Correction & Pre-Charge FET 32-HTSSOP -40 to 85
Technical Details
| Case/Package | HTSSOP EP |
| Frequency | 30MHz |
| Height | 1.15mm |
| High Level Output Current | -1mA |
| Lead Free | Lead Free |
| Length | 11mm |
| Low Level Output Current | 1mA |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Output Current | 80mA |
| Max Power Dissipation | 5.318W |
| Max Supply Current | 65mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 65mA |
| Number of Outputs | 16 |
| Number of Pins | 32 |
| Number of Segments | 16 |
| Output Current | 80mA |
| Output Voltage | 15V |
| Power Dissipation | 5.318W |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 181.096754mg |
| Width | 6.2mm |
