TLC5929DBQR - Texas Instruments
Cut Tape (CT) TLC5929 Shift Register Surface Mount led driver 8.65mm -2mA 5.5V 20MHz
Technical Details
| Case/Package | SSOP |
| Frequency | 28MHz |
| Height | 1.75mm |
| High Level Output Current | -2mA |
| Lead Free | Lead Free |
| Length | 8.65mm |
| Lifecycle Status | Production |
| Low Level Output Current | 2mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Supply Current | 3mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 14mA |
| Number of Outputs | 16 |
| Number of Pins | 24 |
| Operating Supply Voltage | 3.3V |
| Output Current | 50mA |
| Output Voltage | 10V |
| Packaging | Cut Tape (CT) |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 1.5mm |
| Topology | Boost |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| STMicroelectronics | Production | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production |
