Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | VQFN |
| Contact Plating | Gold |
| Dimming | PWM |
| Height | 1mm |
| Lead Free | Lead Free |
| Length | 8mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 85°C |
| Max Output Current | 25mA |
| Max Output Voltage | 5.5V |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 3V |
| Min Input Voltage (DC) | 3V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 2.6V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Channels | 48 |
| Number of Outputs | 48 |
| Number of Pins | 56 |
| Output Current per Channel | 25mA |
| Output Voltage | 10V |
| Packaging | Tape & Reel (TR) |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 900µm |
| Topology | Boost |
| Width | 8mm |
Compliance
RoHS : Unconfirmed
