TLC5973D - Texas Instruments
3-channel, 12-bit PWM constant current LED driver 8-SOIC -40 to 125
Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | SOIC |
| Frequency | 12MHz |
| Height | 1.75mm |
| High Level Output Current | -2mA |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Low Level Output Current | 50mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 6V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 125°C |
| Max Supply Current | 10mA |
| Max Supply Voltage | 6V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Nominal Supply Current | 10mA |
| Number of Channels | 3 |
| Number of Outputs | 3 |
| Number of Pins | 8 |
| Operating Supply Voltage | 5V |
| Output Current | 150mA |
| Output Current per Channel | 50mA |
| Output Voltage | 21V |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 3MHz |
| Thickness | 1.58mm |
| Width | 3.91mm |
