TLC7705MJG - Texas Instruments
SINGLE POWER SVS (5V) W/PGMMABLE "Supervisor Push-Pull, Totem Pole 1 Channel 8-CDIP"
Technical Details
| Case/Package | CDIP |
| Height | 5.08mm |
| Lead Free | Contains Lead |
| Length | 9.6mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 1.05W |
| Max Reset Threshold Voltage | 4.63V |
| Max Supply Current | 16µA |
| Max Supply Voltage | 6V |
| Min Operating Temperature | -55°C |
| Min Reset Threshold Voltage | 4.47V |
| Min Supply Voltage | 2V |
| Number of Pins | 8 |
| Power Dissipation | 1.05W |
| Quiescent Current | 9µA |
| Radiation Hardening | No |
| RoHS | Non-Compliant |
| Schedule B | 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 4.57mm |
| Watchdog Timer | No |
| Width | 6.67mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
